THE THRILL OF RIDING STRIPPED TO ITS BARE ESSENCE
A modern take on what's been putting big grins on the faces of Sportster® motorcycle riders for decades.
Price is for Vivid Black (or solid colour where Vivid Black is not offered). Overseas model shown. The visual appearance and specifications of vehicles may vary by market and may differ from vehicles manufactured and delivered. Please contact your local Harley-Davidson dealership for more information. All comparisons made are between original equipment 2019 and 2020 models
1200cc Evolution™ Engine
Throwback 70's Custom Tank Art
Cafe Solo Seat
Black Mini-Ape Handlebars
Fixed Speed Screen
9-Spoke Cast Aluminium Wheels
- Color Vivid Black
- Price $16,495AUD
- Engine 2 Air-cooled, Evolution™
- Bore 88.9 mm
- Stroke 96.8 mm
- Displacement 1202 cc
- Compression Ratio 10:01
- Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
- Exhaust Black, staggered exhaust and headers with black slash-cut mufflers
- Length 2,200 mm
- Seat Height, Unladen 735 mm
- Ground Clearance 110 mm
- Rake (steering head) (deg) 30
- Trail 117 mm
- Wheelbase 1,515 mm
- Tyres, Front Specification 100/90B19 57H
- Tyres, Rear Specification 150/80B16 77H
- Fuel Capacity 12.5 l
- Oil Capacity (w/filter) 2.6 l
- Weight, As Shipped 248 kg
- Weight, In Running Order 256 kg
- Engine Torque Testing Method EC 134/2014
- Engine Torque 3 97 Nm
- Engine Torque (rpm) 3,250
- Lean Angle, Right (deg.) 27
- Lean Angle, Left (deg.) 28
- Primary Drive Chain, 38/57 ratio
- Gear Ratios (overall) 1st 9.004
- Gear Ratios (overall) 2nd 6.432
- Gear Ratios (overall) 3rd 4.783
- Gear Ratios (overall) 4th 3.965
- Gear Ratios (overall) 5th 3.4
- Wheels, Front Type 7 Black, 9-spoke
- Wheels, Rear Type Black, 9-Spoke
- Brakes, Caliper Type Dual-piston front, Dual-piston rear
- Lights (as per country regulation), Indicator Lamps 6 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
- Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
- Availability of colours may vary from dealer to dealer and is subject to change without further notice.
- Recommended 95 octane or higher fuel (R+M)/2.
- Values shown are nominal. Performance may vary by country and region.
- See motorcycle owner's manual for complete details.
- All models include security system *, 24 months Harley Assist, and 12 months International HOG membership. Price advertised is the maximum dealer ride away price. Offer ends Aug 31, 2018 unless extended. For Australia the ride away price includes 12 months private registration, 12 months Compulsory Third Party Insurance, Dealer Delivery and Stamp Duty ^. Optional extras not included. Full details on pricing can be obtained from your local authorised dealer. ^Ride Away pricing for Australia is based on a purchaser with a good riding record- may be higher for other purchasers that do not meet this criteria.
- Security system includes immobiliser and siren.
- Standard and optional wheels may vary by country and region.
- Model specifications, including fitted parts and accessories vary by country and region.
